DOGE 400132' Ocean King Doge 400 2027

Builder: Ocean King

Model: Doge 400

Year: 2027

External Design: Design aLOT

Interior Design: Margini Architects

Engineering: InNave

Classification: RINA C + HULL • MACH; Y - Unrestricted Navigation

Hull Type: Full Displacement with bow bulb

Hull Material: Steel

Superstructure Material: Light Alloy

LOA: 40.38 m/132 ft

LWL: 35.73 m/117 ft

Max Beam: 8.50 m/27 ft

Draught at Half Load: 2.45 m/8.04 ft

Displacement at Half Load: 390 t

Guest Accommodation: 10 guests in 5 staterooms

Crew Accommodation: 7 crew in 4 cabins

Gross Tonnage: 430 gt

Engines: (2) MAN D2862 LE489 V12*

Power Output at 100/MCR: (2) 1,450 hp/(2) 1,066 kW @ 2,300 rpm

Gearbox: Reinties WAF 464

Propulsion: Direct shaft line with (2) flexible coupling Vulkan Proflex in NiBral class "S" - 5 blades Ø01.450 mm designed to optimize comfort and efficiency

Shafts: Marinox 17 Ø 105 mm

Rudders: AISI 316 stainless steel

Max Speed: 15 knots

Cruising Speed: 10 knots

Range at 9 Knots 1,200 rpm: 5,000 nm

Range at 10 Knots 1,400 rpm: 4,000 nm

Range at 12 Knots 1,750 rpm: 2,850 nm

Gensets: (2) CAT 100 kW 50 Hz 400V; (1) CAT 38 kW 50 Hz 400V

A/C Power: 390,000 btu/h; 50,000 btu/h reserved for cooling

Fuel Tank Capacity: 50,000 liters/13,210 gallons

Fresh Water Tank Capacity: 15,000 liters/3,963 gallons

Black/Grey Water Tank Capacity: 10,000 liters/2,642 gallons

Tender Length Capacity: 3.9 m/13 ft

 *Engine upgrade option available:

   - (2) CAT C32

The skylounge is uniquely openable on three sides, thanks to expansive sliding doors that seamlessly merge indoor and outdoor areas into one harmonious space, offering a stunning 260-degree seascape view.

On this deck, the technologically advanced wheelhouse and the luxurious, comfortable captain's cabin are located strategically.

Key points include:

• Skylounge openable on three sides
• Adjacent advanced wheelhouse and captain's cabin
• Two lounge areas, one located at the aft and one at the bow

The dining room is a private yet accessible segment of the deck thanks to two internal mirrored doors which can isolate the room from the adjacent lobby and pantry.

It offers serene dining experiences with a spectacular sea view, facilitated by full-height sliding doors. Additionally, a large 4K OLED TV enhances the space, serving dual purposes: it provides entertainment and displays vivid paintings and sceneries, setting the mood for every occasion.

The command bridge on the upper deck is a true commercial vessel's workstation.

It is equipped with technologically advanced and complete systems to give shape to the technical room of excellence that blends in with the style of the yacht.

A true command post that, with the help of special touch screens of the highest quality, allows the various on board systems to be monitored and managed thanks to state of the art instrumentation that enables smooth and always effective operations.

Large sliding doors effortlessly blend the indoor and outdoor spaces, creating a vast, unified area, which carries over to the main salon.

Finally, the owner's cabin on this level is the epitome of luxury.

Key points include:

• Salon openable on three sides
• Luxurious owner's cabin with His & Her bathroom with large adjoining walk-in shower

The lounge area, designed with a "U" shaped sofa, creates a convivial or lounge setting perfect for relaxation.

It accommodates a 77-inch TV "framed" by gradient panels with a 3D texture- an innovative, sound-absorbing material that improves sound perception in the salon. Interesting geometric patterns and volume play are achieved through gridded panels that continue from the ceiling to the bulkheads, along with light and shadow effects. This area serves as a cozy yet sophisticated space for guests, blending comfort with cutting-edge design. The incorporation of adjustable lighting enhances the mood, ensuring a seamless integration of form, function, and ambiance, making it an ideal spot for both social gatherings and tranquil moments.

The full beam cabin features a king-size bed, designed to maximize space and ensure unparalleled comfort. The brightness of the room is significantly enhanced by the chosen color schemes, creating an inviting and serene atmosphere. Wall coverings with dual geometric textures and volume play animate the space, adding depth and interest to the cabin's design.

Equipped with a walk-in closet and a desk/study area, the cabin offers ample storage and dedicated space for work or reflection. An integrated sofa/bench on the left side of the ship provides additional seating, perfect for relaxation or reading. A 65-inch TV is strategically placed for optimal viewing, ensuring entertainment is always within reach. This cabin masterfully combines functionality with luxury, offering a private retreat that is both spacious and beautifully illuminated.

The entrance features tempered glass doors, elegantly designed to slide away and disappear, merging seamlessly with the luxurious interior. Inside, a four-lamp infrared sauna offers a modern, health-focused feature, while hammam boasts a double steam outlet and a large rain shower head equipped with 3000k LED lighting, creating a tranquil and immersive experience.

Central to the bathroom's design is the double suspended sink, entirely crafted from marble, serving as the focal point and redefining the space's hierarchies. The feature not only emphasizes the bathroom's elegance but also its commitment to sophistication and functionality.

Complementing the space is a large mirror, behind which lies concealed storage, ingeniously integrating functionality with sleek design. This arrangement ensures a clutter-free environment, enhancing the overall sense of tranquility and luxury.

On this deck, guests are welcomed into four exquisite cabins, each bathroom equipped with waterfall shower heads and bidets, ensuring a luxurious onboard comfort.

Positioned aft, the beach area is particularly noteworthy for its spacious layout. It is an inviting space for guests to relax, as well as accommodating the tender which can be effortlessly launched and retrieved through the side hatch.

Key points include:

• Luxurious, elegant guest cabins
• Tender offloading by side hatch
• Beach area with two openable hatches

The optimization of the lower deck layout has made it possible to incorporate two VIP cabins, each featuring a queen-size bed, along with a desk and a 42-inch TV, offering guests a private, luxurious space. These cabins continue the design theme found throughout, with dual geometric textures on the bulkheads adding depth and visual interest to the space.

Adding to the functionality and style of these cabins, the inclusions of the B&B Italia P60 pouf, a versatile "cube" on wheels, serves as both a seat and easily movable storage solution. This thoughtful addition enhances the cabins' practicality and comfort, ensuring guests have everything they need for a pleasant stay.

This exquisite area is the jewel of the ship, offering versatility and modularity as its defining characteristics. The expansive beach area opens up on two sides with hatches designed to accommodate sun loungers. The area includes a gym, a day head and a sauna designed for two.

Functionally, this space also serves as a storage area for the tender, with a side hatch that allows for the launching and loading of the tender using a crane.

Key points include:

• Spacious and versatile area
• Includes a dayhead, gym, sauna and shower
• Tender garage equipped with telescopic bridge crane, lifting capacity of 1,500 kg

Ocean King is the proud result of over 35 years of experience in crafting commercial steel vessels. Our shipyard is based in Chioggia, within the Venice lagoon, a location steeped in shipbuilding tradition of excellence that spans over nine centuries.

Our journey and evolution have led us to develop a unique approach to luxury yachts. We blend our passion and expertise to create yachts with true Explorer DNA, embodying the perfect synergy of practicality, elegance and seaworthiness.

We honor the sea's unpredictable and wild nature. Our cutting-edge approach to design is born from this reverence. This is why our yachts are meticulously constructed from metal, guaranteeing unmatched sturdiness, dependability, and comfort - qualities that simply cannot be matched by any other material.

An Ocean King offers all this and beyond, ensuring you can enjoy what truly counts: adventure.
