Rachel B36' Jarvis Newman 36 Trawler 1978

1978 Jarvis Newman 36’ Trawler – Classic Downeast Style

Vessel Overview

Name: RACHEL B

Model: Jarvis Newman 36’

Year: 1978

Builder: Jarvis Newman Marine (Southwest Harbor, ME)

Designer: Jarvis Newman

Location: Seabrook, TX

Hull Material: Fiberglass

Length Overall: 36’

Beam: 11’

Draft: 3’6”

Displacement: 16,000 lbs

Fuel Capacity: 260 gallons

Water Capacity: 100 gallons

Holding Tank Capacity: 30 gallons

Description

The 1978 Jarvis Newman 36’ Trawler is a classic Downeast-style cruiser featuring a single diesel engine, flybridge, and two helm stations. Designed for efficiency and seaworthiness, she is perfect for coastal cruising, liveaboard, or extended adventures. With a solid fiberglass hull, classic lines, and a comfortable interior, this vessel is both stylish and practical.

Accommodations

• Forward Cabin: V-berth with adjacent head and shower

• Galley: Equipped with a Hillerange two-burner LPG stove, Norcold 12V refrigerator/freezer, and stainless steel sink

• Main Salon: Spacious with a lower helm station, additional head, and a sliding door leading to the aft cockpit

• Flybridge: Bimini-covered helm station with ample seating

• Cockpit: Large aft deck space with access to the swim platform

Mechanical & Engine Details

• Engine: 2005 Yanmar 6LYA-STE Turbocharged Diesel

• Horsepower: 350 HP @ 3300 RPM

• Hours: 665

• Transmission: Kanzaki KM4A (2.3:1)

• Cooling System: Closed fresh water cooled with sea-water heat exchanger

• Exhaust System: Wet exhaust with PVC water-lift muffler

• Bilge Pumps: Two Rule 1500 GPH automatic submersible pumps

• Generator: Northern Lights 5KW diesel generator (306 hours)

Electrical & Electronics

• Power: 120V shore power / 12V DC ship’s batteries

• Battery Charger: Mastervolt 12V 40A

• Air Conditioning: (1) 16,000 BTU Cruiseair / (1) 12,000 BTU Cruiser

• Electronics: Raymarine RL70 GPS, Radar, and Depth Gauge

Hull & Deck

• Hull Material: Fiberglass with PVC foam core

• Deck Material: Fiberglass/Balsa sandwich with non-skid decking

• Windlass: S&L DC electric windlass

• Stabilizing Mast & Boom: Painted aluminum, in sound condition

• Teak Swim Platform: In good condition

Performance & Sea Trial Results

During the sea trial in 1’ chop, the vessel performed smoothly with no excess vibration and stable temperature readings across all RPM ranges.

• Cruising Speed: ~8.5 knots @ 1850 RPM

• Top Speed: 12.5 knots @ 3200 RPM

Recent Survey Findings

A comprehensive marine survey (Feb 2025) confirms the vessel’s structural integrity and overall average condition for her age. Key recommendations include:

• Servicing/replacing select mechanical components: Bilge pump, seacocks, propeller shaft coupler, oil filter housing, and raw water hoses

• Addressing minor core moisture areas in side decks and cockpit hatches

• Upgrading electronics

Why Buy This Jarvis Newman 36’?

• Timeless Downeast styling with solid construction

• Efficient Yanmar diesel with low hours

• Spacious and comfortable layout for cruising or liveaboard

• Survey available – Transparent condition assessment

This is an excellent opportunity to own a sought-after classic trawler at an attractive price. With some maintenance and upgrades, she’ll be ready for her next adventure.

For a copy of the recent survey or to schedule a viewing, contact: Burke 281-734-6625 (Call or Text) email Burke@LittleYachtSales.com
